Dream Machine Pro Max (UDM-Pro-Max) – High-Performance 10G Cloud Gateway for Enterprise Networks

Availability:

In stock


Short Description :

  • 5 Gbps routing with IDS/IPS
  • 10G SFP+*, (8) GbE RJ45 LAN ports
  • 10G SFP+*, (1) 2.5 GbE RJ45 WAN ports
  • 3.5″ NVR HDD bays with RAID data protection
  • Built-in 128 GB SSD for NVR detection recordings
  • UniFi Power Backup ready
  • 1.3″ touchscreen



71,544৳

In stock

EMI starts at 2,641৳  - View Banks EMI Plans

Dream Machine Pro Max (UDM-Pro-Max) – High-Performance 10G Cloud Gateway for Enterprise Networks

The Dream Machine Pro Max (UDM-Pro-Max) offers unparalleled performance for enterprise networks, supporting over 200 UniFi devices and 2,000+ clients.  this powerful 10G Cloud Gateway delivers 5 Gbps IPS routing, redundant NVR storage, and advanced computing capabilities for enhanced device and client capacity.

Key Features:

  • Enhanced Performance: 5 Gbps routing with built-in IDS/IPS for superior network security and performance.
  • Expandable Connectivity: Includes (1) 10G SFP+, (8) GbE RJ45 LAN ports, and (1) 10G SFP+ and (1) 2.5 GbE RJ45 WAN ports for versatile networking.
  • Redundant NVR Storage: Two 3.5″ NVR HDD bays with RAID data protection, plus a built-in 128 GB SSD for NVR detection recordings.
  • UniFi Power Backup Ready: Ensures continuous operation with power backup support for maximum reliability.
  • Touchscreen Interface: A 1.3″ touchscreen for easy monitoring and management of your network.

Advanced Hardware Specifications:

  • Processor: Quad-core ARM® Cortex®-A57 at 2.0 GHz for high-speed processing.
  • Memory: 8 GB DDR4 system memory with 32 GB eMMC and integrated 128 GB SSD.
  • Power Supply: Internal AC/DC, 100W with universal AC input (100—240V AC) and USP-RPS DC input for power redundancy.

Next-Gen Security & Networking:

  • Advanced Security: Application-aware firewall, IPS/IDS threat detection, content filtering, and VLAN-based traffic segmentation.
  • Networking Features: License-free SD-WAN, VPN support (WireGuard, OpenVPN, IPsec), and policy-based WAN and VPN routing.
  • Internet Failover: LTE backup and redundant WAN with failover and load balancing for uninterrupted service.

Perfect for large-scale networks, the Dream Machine Pro Max provides cutting-edge performance, security, and flexibility to meet the demands of modern businesses.

Dream Machine Pro Max (UDM-Pro-Max) – 10G Cloud Gateway with Advanced Security and High Performance for Enterprise Networks

Lastly, You can buy this product from Best Computer Hub Ltd. The latest price of  Dream Machine Pro Max (UDM-Pro-Max)  in Bangladesh is  ৳. Order Online Or Visit your Nearest Best Computer Hub Shop to get yours at lowest price.



Category Details
Mechanical Dimensions 442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2″)
Weight 4.7 kg (10.4 lb)
Enclosure Material Aluminium CNC, SGCC steel
Mount Material SGCC steel
Hardware
Processor Quad-core ARM® Cortex®-A57 at 2.0 GHz
System Memory 8 GB DDR4
On-board Storage 32 GB eMMC
Integrated 128 GB SSD
Management Interface Ethernet, Bluetooth
Networking Interface LAN: (8) GbE RJ45 ports, (1) 10G SFP+ port
WAN: (1) 2.5 GbE RJ45 port, (1) 10G SFP+ port
IDS/IPS Throughput 5 Gbps*
Power Method (1) Universal AC input, 100—240V AC, 2A Max., 50/60 Hz
(1) USP-RPS DC input, 11.5V DC, 8.7A
Power Supply AC/DC, internal, 100W
Supported Voltage Range 100—240V AC
Max. Power Consumption 100W
ESD/EMP Protection Air: ± 15kV, contact: ± 8kV
LCM Display (1) 1.3″ touchscreen
Button Factory reset
Operating Temperature -10° to 40° C (14° to 104° F)
Operating Humidity 5 to 95% noncondensing
Certifications CE, FCC, IC
Gateway Features
Performance Redundant WAN with failover and load balancing, WiFi QoS with UniFi APs
Application, domain, and country-based QoS
Application and device type identification
Additional internet failover with LTE Backup
Internet quality and outage reporting
Security Application-aware firewall rules, Signature-based IPS/IDS threat detection
Content, country, domain, and ad filtering, VLAN/subnet-based traffic segmentation
Full stateful firewall
Advanced Networking License-free SD-WAN, WireGuard, L2TP and OpenVPN server, OpenVPN client
OpenVPN and IPsec site-to-site VPN, One-click Teleport and Identity VPN
Policy-based WAN and VPN routing, DHCP relay, Customizable DHCP server
IGMP proxy, IPv6 ISP support
LEDs Ethernet: Green: link/activity, SFP+: Green: link/activity
HDD: White: disk activity, Amber: disk error
RPS: Blue: ready
