ASUS PRIME H610I-PLUS D4 Mini ITX Motherboard
ASUS PRIME H610I-PLUS D4 Mini ITX Motherboard - Image 2
ASUS PRIME H610I-PLUS D4 Mini ITX Motherboard - Image 3
ASUS PRIME H610I-PLUS D4 Mini ITX Motherboard
, , , , , ,

ASUS PRIME H610I-PLUS D4 Mini ITX Motherboard

Asus
Availability:

In stock
Add to wishlist
Compare

Short Description

  • Model: PRIME H610I-PLUS D4
  • Supported CPU: 14th/13th/12th Gen Intel Processors (LGA1700)
  • Supported RAM: 2x DDR4, Max 64GB 3200
  • Graphics Output: 1x HDMI port, 1x DisplayPort, 1 x D-Sub
  • Features: 1 x Realtek 1Gb Ethernet

16,900৳  18,700৳

In stock

EMI starts at 624৳  - View Banks EMI Plans

ASUS PRIME H610I-PLUS D4 Mini ITX Motherboard: Compact Power and Performance

The ASUS PRIME H610I-PLUS D4 Mini ITX motherboard is designed for compact yet powerful PC builds. Featuring the Intel H610 chipset and supporting Intel LGA 1700 sockets, it is compatible with 14th, 13th, and 12th Gen Intel Core processors, making it an excellent choice for modern computing needs.

Engineered for stability, this motherboard features a 5+1+1 DrMOS power stage system that ensures reliable performance, while its comprehensive cooling solutions include VRM and PCH heatsinks and Fan Xpert technology for efficient thermal management, even during heavy loads.

For high-speed data transfer, the ASUS PRIME H610I-PLUS D4 Mini includes a 32Gbps M.2 slot and multiple USB 3.2 Gen 1 ports. Networking is seamless with Realtek 1Gb Ethernet, ensuring fast and stable internet connections for gaming, streaming, and multitasking.

The motherboard offers versatile display options with DisplayPort, HDMI, and D-Sub outputs, making it ideal for multi-monitor setups. It also features SATA 6 Gbps ports for quick data access and storage capabilities, along with COM and mono-out headers supported by an Amp IC for expanded peripheral connectivity.

Built with durability in mind, the ASUS PRIME H610I-PLUS D4 Mini incorporates 5X Protection III, a suite of hardware safeguards to ensure long-lasting reliability. This motherboard combines robust performance, excellent cooling, and reliable connectivity, making it the perfect solution for users looking to build a powerful and compact PC.

Backed by a 3-year warranty, the ASUS PRIME H610I-PLUS D4 Mini offers both peace of mind and powerful functionality for your next compact system build.

What is the price of  Asus PRIME H610I-PLUS D4 Mini Motherboard in Bangladesh?

Lastly, You can buy this product from Best Computer Hub Ltd. The latest price of Asus PRIME H610I-PLUS D4 Motherboard in Bangladesh is 17,000৳.

So, Order Online Or Visit your Nearest Best Computer Hub Shop to get yours at lowest price.

SKU: Asus-Intel-Motherboard-0013 Categories: , , , , , , Tags: , , , ,
Basic Information
Supported CPU Intel Socket LGA1700 for Intel Core 14th & 13th Gen Processors, Intel Core 12th Gen, Pentium Gold and Celeron Processors
Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0
Chipset Intel H610 Chipset
BIOS 128 Mb Flash ROM, UEFI AMI BIOS
Form Factor Mini ITX Form Factor
6.7 inch x 6.7 inch ( 17.02 cm x 17.02 cm )
Audio Realtek 7.1 Surround Sound High Definition Audio CODEC*
– Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
– Supports up to 24-Bit/192 kHz playback
Audio Features
– Audio Shielding
– Dedicated audio PCB layers
Expansion Slots
PCI Intel 14th & 13th & 12th Gen Processors
1 x PCIe 4.0 x16 slot
M.2 Socket 1 x M.2 slots
Memory
Type DDR4
Slots 2x DIMM
Supported Memory 3200/3000/2933/2800/2666/2400/2133 Non-ECC, Un-buffered Memory*
Dual Channel Memory Architecture
Supports Intel Extreme Memory Profile (XMP)
Maximum Memory Max. 64GB
Graphics
Graphics Support DisplayPort 1.4 with max. resolution of 4K@60Hz.
Support HDMI® 2.1 with max. resolution of 4K@60Hz.
Connector & Ports
HDMI 1 x HDMI port
D-Sub (s) 1 x D-Sub
USB (s) Rear USB (Total 4 ports)
2 x USB 3.2 Gen 1 ports (2 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
Front USB (Total 4 ports)
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
1 x USB 2.0 header supports additional 2 USB 2.0 ports
LAN Port (s) 1 x Realtek 1Gb Ethernet port
Wireless Communication module M.2 slot only (Key E, CNVi & PCIe)
*Wi-Fi module is sold separately.
Supported Storage Total supports 1 x M.2 slot and 4 x SATA 6Gb/s ports
Intel H610 Chipset
M.2 slot (Key M), type 2260/2280 (supports PCIe 3.0 x4 mode)
4 x SATA 6Gb/s ports
Audio 3x Audio jacks
Internal I/O Ports Fan and Cooling related
1 x 4-pin CPU Fan header
1 x 4-pin CPU OPT Fan header
1 x 4-pin Chassis Fan header
Power related
1 x 24-pin Main Power connector
1 x 8-pin +12V Power connector
Storage related
1 x M.2 slot (Key M)
4 x SATA 6Gb/s ports
USB
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
1 x USB 2.0 header supports additional 2 USB 2.0 ports
Miscellaneous
1 x Clear CMOS header
1 x COM Port header
1 x Front Panel Audio header (AAFP)
1 x Mono-out header(with Amp IC)
1 x SMBUS header
1 x Speaker header
1 x SPI TPM header (14-1pin)
1 x 10-1 pin System Panel header
Others
Special Features ASUS 5X PROTECTION III
– DIGI+ VRM
– LANGuard
– Overvoltage Protection
– SafeSlot Core
– Stainless-Steel Back I/O
ASUS Q-Design
– Q-DIMM
– Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
– Q-Slot
ASUS Thermal Solution
– Aluminum heatsink design
Warranty Information
Manufacturing Warranty 3 years warranty
